Ultraflow U3000 Ultrasonic Flowsensor

The Ultraflow brings simplicity to the non-invasive measurement of liquid flow, offering the user quick and accurate flow measurement with its easy to follow menu and simple set up. Dry servicing, providing minimum downtime and maximum availability, even in a continuously running system. Compact, rugged and reliable, the Ultraflow has been designed to provide sustained performance in industrial environments.


  • Principle: non-contact ultrasonic transit time
  • Measuring range: 0.1…20m/s
  • Pipe size [d]: 13…2000mm
  • Pipe materials: Plastics and steel
  • Output: 4-20mA, 4-wire; Pulse
  • Integrated display and programming buttons
  • Supply power: 12…24V AC/DC, 110/230V AC
  • Includes transducer guide rail and all mounting hardware
