Baumann™ 51000 High-Pressure, Low-Flow Control Valve
- Certifications
- PED, CUTR, ATEX
- Critical Service
- Low Flow
- Flow Characteristics
- Modified Equal Percentage
- Material
- Stainless, Alloy
- Operating Temperature
- Standard Temperature
- Pressure Class
- 3000 psi CWP
- Process Connection Type
- Threaded
- Shutoff Class
- Class IV (FCI 70-2), Class VI (FCI 70-2)
- Valve Size
- NPS 1/4, NPS 1/3
- Valve Size Standard
- NPS
- Other Configurations
- Contact your local Emerson business partner or sales office to learn about additional specifications or options for this product.
Features
- Features a compact size.
- Suitable for sticky fluids and corrosive atmospheres.
- Investment cast stainless steel body in 1/4 and 1/2 inch sizes or barstock N10276 nickel alloy. Other alloys available.
- Class VI shutoff with soft seat available. Up to 207 barg (3000 psig) at 370° (1000°F).
- Rugged bolted bonnet design.
- Wide flow capacity range. Maximum rated Cv ranges from 0.00013 to 2.5 (0.0002 to 2.16 Kv).
- Actuator is corrosion-resistant.
- Available without positioner for fail open or fail close applications.
