GeoMax Micro-Robotic (Zoom-3D)

Brand : GeoMax

Model : Zoom-3D

Country: Switzerland

Easy-to-use and fast 3D measuring instruments, the Zoom3D Series are ideal for indoor as well as outdoor
applications. Upgraded it to an innovative and user-friendly robotic total station: simply position it and turn
it on, the Zoom3D will measure and layout any project site.

With very simple con guration and equipped with an auto levelling feature, the Zoom3D is a plug-and- play solution that speeds up your daily tasks. Its user-friendly onboard software helps with a wide range of indoor applications such as measuring, setting out or plumbing points. Levelling can now be completed with greater ease and speed, then exported in most common le formats.For your outdoor tasks, the Micro Robotic Solution is equipped with target recognition technology that automatically and easily centres and follows the target, allowing surveys and stakeouts in small construction sites.

Measurement range Horizontal 360°; vertical 250°
Accuracy 5˝, equates to 1.2 mm @ 50 m
Type Coaxial, visible red laser
Measurement range 0.5 – 50 m
Laser class 2
Laser type 650nm; < 1mW ø laser dot (at distance) 10 m: ~7 mm ×7 mm 30 m: ~9 mm ×15mm TIE DISTANCE ACCURACY (3D) Angle and distance combination @10 m @30 m @50 m Approx. 1 mm 2 mm 4 mm TILT SENSOR Self-levelling range ±3° Accuracy 10˝, equates to 2.5 mm @ 50 m DIGITAL POINT FINDER Zoom (magni cation) / Field of view (@ 10 m) 1× / 3.40m × 2.14m 2× / 1.70 m × 1.07 m 4× / 0.85 m × 0.54 m 8× / 0.42 m × 0.27 m CIRCULAR LEVEL SETTING Accuracy 1°/mm (Accuracy is speci ed at 20°C; ** Depending on environment) OPERATION Keys/user interface 1 on /o button Interfaces USB type B, power supply power pack COMMUNICATION Cable USB: Micro-B USB and type a; WLAN Wireless 50m range ** POWER SUPPLY Internal battery Li-Ion battery 14.4 V / 63 Wh External power 24 VDC / 2.5A, charging time 8 h Operating time 8 h PHYSICAL SPECIFICATIONS Dimensions Height 215.5 mm, ø 186.6 mm Weight 2.8 kg Operating temp. –10°C to 50°C Storage temp. –25°C to 70°C Protection class IP54 (IEC 60529) Attachment 5 8” thread REMOTE CONTROL Range 50 m ** Communication Infrared (IR) Battery 1 AA, 1.5 V
